1.生産紹介
2.製品 寸法 そして 許容範囲 範囲
|
Thickness(mm) |
Tolerance(mm) |
Width(mm) |
Tolerance(mm) |
|
0.008-0.018 |
±0.0012 |
300-550 |
±0.1 |
|
0.019-0.034 |
±0.0015 |
300-550 |
±0.1 |
|
0.035-0.05 |
±0.002 |
300-550 |
±0.1 |
|
0.06-0.08 |
±0.003 |
300-550 |
±0.1 |
3.合金 指定、 化学薬品 構成
|
Designation |
Chemical Composition(%) |
|||||
|
Cu |
Pb |
Fe |
Zn |
P |
O |
|
|
C1100 |
≥99.95 |
<0.02 |
<0.02 |
<0.02 |
<0.02 |
<0.3 |
|
C2680 |
64-67 |
<0.05 |
<0.03 |
<0.36 |
<0.02 |
/ |
4.物理的特性
|
Designation |
Physical Properties |
|||||
|
Specific(g/cm²) |
Coefficient of thermal expansion |
Thermal conductivity |
Electrical conductivity |
Resistivity |
Modulus of elasticity |
|
|
C1100 |
8.92 |
17.3*10-6 |
373 |
101.5 |
0.0168-0.0176 |
115 |
|
C2680 |
8.47 |
20.1*10-6 |
116 |
27 |
0.06-0.07 |
105 |
5.機械的性質
|
Designation |
Temper |
Tensile Strength |
Elongation |
Hardness |
|
C1100 |
H |
≥120Mpa |
≥5% |
--- |
|
C2680 |
H |
≥600Mpa |
≥3% |
≥160 Hv0.2 |
6.応用分野
圧延銅箔は主に5G製品、3C製品、新エネルギー車、ソフト接続部品、充電機器に使用されます。銅合金箔は主に車両コネクタ、コネクタ、ディスクリート部品に使用されます。
